Product Performance

The 3-ton glycol chiller uses ethylene glycol as the cooling medium, with an adjustable outlet temperature ranging from 0°C to -35°C. It's suitable for low-temperature cooling, low-temperature processes, and low-temperature constant-temperature requirements that ordinary chillers cannot meet, making it applicable to a wider range of industrial scenarios.

The 8hp glycol chiller works by using a scroll compressor to circulate and compress the refrigerant, achieving cooling through an external condenser fan and finned heat exchanger. The cooling medium in the circulation system is a mixture of ethylene glycol, which does not freeze at low temperatures, ensuring safe operation of the equipment. Temperature control accuracy reaches ±0.05°C, achieving precise temperature control.

This water-cooled glycol chiller can be applied in many industries, such as food, craft brewing, low-temperature fermentation, chemical, pharmaceutical, and electronics, and is a very popular chiller.

Model Items			ICA-8M	ICA-8L	ICA-8U
Cooling capacity		kW	11.0	7.4	6.3
		10³ kcal/h	9.5	6.5	5.4
Power source		V/ph/Hz	380/3/50	380/3/50	380/3/50
Total power input		kW	7.8	9.0	5.7
Rated current		A	15.0	20.5	12.5
Compressor	Type		Scroll type
	Power input	kW	6.2	7.2	4.1
	Quantity	net	1
Condenser	Type		Efficient internal thread fin type
	Max. Press.	bar	45
Cooling fan	Fan type		Efficient axial flow
	Fan quantity	net	2
Evaporator	Type		Stainless shell and tube (stainless heat exchange tube)
	Water press.	bar	16
Pump	Type		Stainless steel centrifugal type
	Head	m	25	45	45
	Power	kW	0.75	1.3	1.3
	Flow rate	m³/h	1.9	1.3	1.08
Tank capacity		L	100
Water pipe size		DN	25
Protection			Pressure,overload,Antifreeze, Delay, Over temperature, Flow Protection
Noise		db(A)	64	64	68
Weight		kg	260	240	210
Dimensions(LWH)		mm	13506801360
Package dimensions		mm	15508101420
Gross weight		kg	300

Our advantages

With 20 years of professional R&D and manufacturing experience, mature processes, and continuous innovation, we are China's largest chiller production base. We offer OEM and ODM services, and manufacture many key components ourselves, ensuring product quality from the source.

What authoritative certifications does Kangcai have?

We have passed ISO9001 quality management system certification, ISO14001 environmental management system certification, CE certification, energy-saving certification, and multiple national invention patents.

What compressor brands are available?

Standard options include internationally renowned brands such as Copeland and Hanbell, as well as Bitzer and Haili compressors, all offering original manufacturer warranties.

What are the functions of the control system?

All models come standard with a touchscreen PLC control system, featuring temperature curve recording, fault self-diagnosis, remote monitoring, mobile app alarm, and energy efficiency analysis. Integrated control systems are also available.
